3.2V 176AH Lifepo4 Battery Cell Lifepo4 Electric Car Batteries

3.2V 176AH Lifepo4 Battery Cell Lifepo4 Electric Car Batteries

    • 3.2V 176AH  Lifepo4 Battery Cell Lifepo4 Electric Car Batteries
    • 3.2V 176AH  Lifepo4 Battery Cell Lifepo4 Electric Car Batteries
    • 3.2V 176AH  Lifepo4 Battery Cell Lifepo4 Electric Car Batteries
  • 3.2V 176AH  Lifepo4 Battery Cell Lifepo4 Electric Car Batteries

    Product Details:

    Place of Origin: China (Mainland)
    Brand Name: QH
    Model Number: QH-LFP72174138-176AH

    Payment & Shipping Terms:

    Minimum Order Quantity: 4pcs
    Price: Negotiable
    Packaging Details: carton packing
    Delivery Time: 4-7 days
    Payment Terms: T/T
    Supply Ability: 10000
    Contact Now
    Detailed Product Description

    3.2V 176AH Lifepo4 Battery Cell Lifepo4 Electric Car Batteries



    Model QH-LFP72174138-176AH
    Casing material for single cell Aluminum shell
    Nominal Voltage 3.2V
    Cut-off Voltage Charging: 3.65V
    Discharging: 2.5V
    Capacity 176AH
    Keywords Lifepo4 Prismatic Battery cell
    Internal Resistance ≤ 0.8mΩ
    Charging Current 35.2A (Standard Charging)
    Max Charge Current 176A
    Const. Discharge Current 176A
    Max Discharge Current 264A
    DOD 80%
    Life Cycle 5000 times
    Dimension D54*W173*H201 MM
    Cell Weight 3.82 KG
    Safety Protection Over Charging
    Over Discharging
    Short Circuit
    Penetration
    Thermal shock
    No Fire/Explosion

    Our Guarantee:



    Ensure that the product undergoes rigorous inspection before leaving the factory to ensure that the quality of the manufactured product is qualified. In addition to, we promise that this project will be free from maintenance and assembly defects within two years from the date of purchase. Warranty applies only to material or operational defects that occur at the time of purchase. In the meantime, we will repair or replace the products that are deemed defective for these reasons. You will be asked to provide proof of purchase (invoice or receipt). This warranty does not apply to any damage or consequential damage resulting from incorrect application, modification or failure to follow the procedures described in this manual. Therefore, it is hoped that you can read the instructions carefully and follow the instructions before using this product.





    Battery quality control for after-sale



    All QH batteries in the package have a high degree of consistency. In a group, each cell has after-sales service for quality control. Your own electronic code (ID number), assuming that one cell in the package was damaged in a few years, we can provide customers with exactly the same cell to replace the damaged cell (same voltage, capacity, impedance, etc.) To ensure that all the cells in this package have a very high consistency. Melsen has a strong system for this job.





    Application

       1. electrical and hobby

    2. User application

    3. Solar lawn, can be used as a remote controller

    4.electrical tools

    5. Electric vacuum cleaners, electric cleaners.

    6. When an emergency occurs, it can be used as an emergency power source, LED light and flashlight.

        7. Backup power supply, medical equipment, etc.
