| Place of Origin: | China |
| Brand Name: | QH |
| Certification: | CE ROHs LC |
| Model Number: | lifepo4 |
| material: | lifepo4 |
|---|---|
| voltage: | 12v |
| capacity: | 100ah |
| Cont. Discharge: | 80A |
| Discharge Temperature: | -20℃ ~ 60℃ |
| cycle life: | more than 2000 times |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | carton packing |
| Item | Specification | Note |
| Nominal Voltage: | 12V | Any voltage can be customized |
| Nominal Capacity: | 100Ah | Any capacity can be customized |
| Discharge Cut-Off: | 8V | |
| Charge Cut-Off: | 14.6V | |
| Charge Current: | 20A | Free customization service |
| Cont. Discharge: | 20A | Free customization service |
| Peak Discharge: | 30A | Free customization service |
| Impedance: | ≤200mΩ | |
| Charge Temperature: | 0℃ - 45℃ | |
| Discharge Temperature: | -20℃ - 60℃ | |
| Charge Method: | CC/CV | |
| Life Cycle: | 2000+ | 80% DOD, Max. 95% DOD |
| BMS: | With BMS | |
| Dimension: | 330mm*175mm*220mm | Any dimension can be customized |
| Weight: | 19KG |
Advantages:
FAQ
Q1. Can QH TECHNOLOGY ship battery out of China?
R1: Yes, we can ship to any country out of China, you can tell us your address to check.
Q2. How does QH TECHNOLOGY ship the LiFePo4 battery packs?
R2: For sample order or small battery packs, we can ship by express through Fedex, UPS, TNT etc. If whole parcel over 100KG, can ship by air or by sea,sea shipping is more cheaper.
Customer can tell your nearest airport name and sea port name for Lithium Valley sales person to check the best option for you.
Q3. Can we put different LiFePO4 battery pack in parallel or series by ourself?
R3: Yes. The battery can be put in parallel or series by customers. But there are few tips we need to pay attention;
1> Make sure the voltage of each battery are same before put inparallel. If they are not same, charge them to the same rate.
2> Don't not put discharged battery and undischarged battery in parallel. This may reduce the capacity of the whole battery pack.
3> Advise us the target capacity of the whole pack if you would like to put them in series. We will choose the suitable BMS for each battery.
4> If you are not professional in parallel and series batteries, please don't handle the battery by yourself.
It may cause danger and hurt the cycle life of battery.
Q4. Does your battery pack include BMS? Can we use it for car?
R5: Yes, our battery pack include BMS, you can use it for electric car. Smart BMS with Telecommunicaion functions is optional.
Q6. What is your warranty?
R6:We offer 2 years warranty for all our battery pack. we ensure at least 2000 cycle life for the LiFePO4 battery pack, which means, after 2000@80% DOD, there will still around 60% capacityt left. You can use it for at least 8 years for normal 1 time charge and discha
Those Who Are Looking For A Professional Manufacturer For 12V, 100AH Lifepo4 Battery Pack, At Factory Price, With Top Quality, PLEASE FEEL FREE TO CONTACT US
