| Specifications: | |
| Model | QH-LFP36130200-90 |
| Casing material for single cell | Aluminum shell |
| Nominal Voltage | 3.2V |
| Capacity | Max:90Ah |
| Min: 89Ah | |
| Core size | D36*W130*H200MM |
| Cell Weight | 2.0KG ±20g |
| Charging Current | Standard Charging: 5A (0.2C rate) |
| Max. Charging: 25A (1C rate) | |
| Max Discharging Rate | Max Continuous Discharging:3C |
| Max Peak Discharging:5C | |
| Cut-off Voltage | Charging:3.65V |
| Discharging:2.5V | |
| Internal Resistance | ≤ 0.8mΩ (At 0.2C rate, 2.0V cut-off) |
| Working Temperature | Charging: -10℃~45℃ |
| Discharging: -20℃~60℃ | |
| Storage Temperature | ≤1month: -10–45℃ |
| ≤3month: 0–30℃ | |
| ≤6month: 20±5℃ | |
| Life Cycle | >2000 times (80% of initial capacity at 0.2C rate, IEC Standard) |
| Global Insurance OEM/ODM | |
Deep Cycle Long Lifespan Li ion Battery ESS 3.2V 90AH LiFePO4 Batteries Cell
Deep Cycle Long Lifespan Li ion Battery ESS 3.2V 90AH LiFePO4 Batteries Cell
Main Feature: lithium battery high power LiFePO4 cells - high quality lithium ion phosphate battery for all kinds of lithium cells applications; long life sapn which can reach up to 2000 times
Benefits
Application
1) Electric vehicles and charging stations, tourist coaches, yachts, wind and solar energy storage power, traffic signals
2) Solar hybrid street lighting, UPS power supply, home storage
3) Coal, disaster relief emergency, weather radar, electricity, smart grid, communication base stations
4) Hospitals, finance, telecommunications , system critical backup power systems
