| Place of Origin: | China |
| Brand Name: | QH |
| Certification: | CE ROHs LC |
| Model Number: | lifepo4 |
| material: | lifepo4 |
|---|---|
| voltage: | 12v |
| capacity: | 90ah |
| Size: | 173*326*220mm |
| charging volt: | 14.6v |
| cycle life: | more than 2000 times |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | carton packing |
12v lithium battery 12 volt 60ah lithium ion battery producer for electric forklift
12v lithium ion battery packs are supplied by QH, one of the top battery manufacturers and lithium battery producers for solar pv battery storage, solar storage battery and UPS battery.
Voltage :12V | Capacity:75Ah/85Ah/90Ah/120Ah/170Ah/240Ah or Customized;
| Normal Voltage | 12V |
| Nominal Capacity | 90Ah |
| Internal Resistance | ≤60mΩ |
| Cycle Life | >2000 cycles @1C 100%DOD |
| Months Self Discharge | <3% |
| Efficiency of Charge | 100% @0.5C |
| Efficiency of Discharge | 96~99% @1C |
| Charge Voltage | 14.6±0.1V |
| Standard Charge Model | 0.2C to 14.6V, then 14.6V,charge current to 0. 02C (CC/CV) |
| Continuous Charge Current | 45(≤0.5C) |
| Max.Charge Current | 90A (1C) |
| Charge Cut-off Voltage | 14.6±0.1V |
| Continuous Current | <90A (1C) |
| Max. Pulse Current | 180A(<3s) (2C) |
| Discharge Cut-off Voltage | 10V |
| Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
| Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity |
| Water Dust Resistance | IP56 |
| Plastic Case | ABS |
| Dimensions (mm) | 173*326*220mm |
| Terminal | T2 |
12v lithium ion battery packs are supplied by QH, one of the top battery manufacturers and lithium battery producers for solar pv battery storage, solar storage battery and UPS battery.
If you are looking for 12v lithium ion battery, top battery manufacturers, lithium battery producers or solar pv battery storage, please feel free to contact me. Samples are cheap.
