| Place of Origin: | China |
| Brand Name: | QH |
| Certification: | CE ROHs LC |
| Model Number: | lifepo4 |
| Material: | LiFePo4 |
|---|---|
| Voltage: | 200V-900V |
| Capacity: | 200KWH |
| Warranty: | 10years |
| Lifecycle: | 6000Times |
| Shape: | Container or Cabinet or Rack |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | carton packing |
200 Kwh Battery, High Voltage Battery, Lithium Ion Battery Energy Storage Systems
For commercial buildings such as schools, factories and petrol stations that require higher energy demand, solar PV system with battery storage can enable business to maximise their energy independence and reduce peak power demand; For business without solar PV system, battery storage can enable business to store energy from the grid at off peak price and use at peak time.
200KWH Battery Solutions
| Model | QH-LFP200-HV | Remark |
| Rated voltage | 460V | Can be Cusomized |
| Rated capacity | 275Ah | Can be Cusomized |
| Standard charge | Constant current at 0.3C | Can be Cusomized |
| Standard discharge | Constant current at 0.5C | Can be Cusomized |
| Max. charge current | 138A (0.5C) | Can be Cusomized |
| Max. discharge current | 275A (1C) | Can be Cusomized |
| Cut off Charging Voltage | 525.6V | / |
| Cut off Discharging Voltage | 360V | / |
| Operating temperature | Charge:0~45 deg.C; | / |
| Discharge:-20~65 deg.C | / | |
| Storage temperature | -10~45 deg.C less than 3 months; | / |
| - 0~25 deg.C less than 1 year | / | |
| Storage humidity | 25 to 90% RH | / |
| Weight | 3000KG | / |
| Size | 20ft | / |
| Long cycle life | More than 6000 times(100% DOD) | / |
| Internal resistance | <100 mΩ | / |
Battery Energy Storage Systems Solutions
Features:
Battery Monitor PC System
Battery Monitor Mobile APP
Battery Single Cells
3.2 volt lifepo4 solar battery suppliers & manufacturers & producers for wholesale d
Battery Module
Master- Slave BMS
QH ESS200kwh provides one-stop solutions for commercial and industrial facilities to reduce your electricity bill, protect your business from rising energy expenses; generate stable revenue from renewable energy production and subsidies; and ultimately reduce carbon footprint.
